GIGABYTE X870E AORUS MASTER Motherboard - AMD X870E - ATX
Our shoppers love
£439.99 from Amazon.co.uk
- Supports AMD Ryzen 7000/8000/9000 Series processors •
- DDR5 RAM up to 4000 MHz •
- PCIe 5.0 and PCIe 4.0 expansion slots •
- Multiple USB4 and HDMI ports •
- More features
Offers updated on: 14/09/2025. Paid and non-exhaustive ads. ★ The ratings are generated from multiple sources, including data provided by the merchant and publicly available information.
Description
Introducing the GIGABYTE X870E AORUS MASTER Motherboard, a powerhouse that redefines computing performance since its release. Built for AMD processors, this ATX motherboard is ready to elevate your PC setup to unprecedented heights.
Designed to support the latest AMD Ryzen 7000, 8000, and 9000 series processors, the GIGABYTE X870E features the cutting-edge Socket AM5. With a maximum internal memory support of 256 GB, it’s perfect for high-demand applications and multitasking scenarios.
The motherboard supports advanced DDR5-SDRAM memory, ensuring lightning-fast performance with a maximum clock speed of 8600 MHz. With four DIMM slots available, users can easily expand their system memory as their needs grow.
- Processor Manufacturer: AMD
- Compatible Processor Series: Ryzen 7000/8000/9000
- Internal Memory Support: Up to 256 GB
- Memory Types Supported: DDR5-SDRAM
Storage options are abundant with support for both HDDs and SSDs through M.2 and SATA III interfaces, accommodating up to 8 drives. RAID support enhances performance and reliability, making this motherboard ideal for data-intensive tasks.
- Storage Drive Types: HDD & SSD
- Number of Storage Drives Supported: 8
- RAID Levels Supported: 0, 1, 10
The GIGABYTE X870E is also packed with connectivity options. It features USB 2.0, USB 3.2 Gen1, Gen2x2 connectors, and HDMI for versatile peripheral and display connections. Its built-in Ethernet LAN and WiFi 7 ensure you stay connected at high speeds.
- USB Ports: 2 x USB 2.0, 4 x USB 3.2 Gen1, 4 x USB 3.2 Gen2, 2 x USB4 Gen2x2
- Networking: 5 Gigabit Ethernet, Wi-Fi 7
Whether you're building a gaming rig, setting up a workstation, or constructing a server, the GIGABYTE X870E AORUS MASTER is equipped to handle it all. With various fan connectors for optimal cooling and RGB headers to customize your setup’s appearance, it’s both functional and visually appealing.
- Fan Connectors: 2 CPU fan, 6 chassis fan
- RGB LED Pin Headers: 5
In conclusion, the GIGABYTE X870E AORUS MASTER Motherboard combines power, connectivity, and flexibility. Ideal for gamers, content creators, and professionals, it promises a robust performance for years to come. Upgrade your PC with this exceptional motherboard.
Features
Processor
- Processor manufacturer:AMD
- Processor socket:Socket AM5
- Compatible processor series:AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Supported processor sockets:Socket AM5
- Maximum internal memory supported by processor:256 GB
Memory
- Supported memory types:DDR5-SDRAM
- Number of memory slots:4
- Memory slots type:DIMM
- Memory channels:Dual-channel
- ECC сompatibility:ECC & Non-ECC
- Supported memory clock speeds:4400,4800,5200,5600,6000,6200,6400,6600,6666,6800,7000,7200,7600,7800,8200,8400,8600 MHz
- Supported memory clock speed (max):8600 MHz
- Maximum internal memory:256 GB
- Supported memory module capacities:1GB, 2GB, 4GB, 8GB, 12GB, 24GB, 32GB
- Unbuffered memory:Yes
- Maximum internal memory per slot:64 GB
Storage controllers
- Supported storage drive types:HDD & SSD
- Supported storage drive interfaces:M.2, SATA III
- Number of HDDs supported:4
- Number of storage drives supported:8
- RAID support:Yes
- RAID levels:0, 1, 10
Graphics
- Parallel processing technology support:Not supported
- On-board graphics card:No
- DirectX version:12.0
Internal I/O
- USB 2.0 connectors:2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors:2
- USB 3.2 Gen 2x2 connectors:1
- Number of SATA III connectors:4
- Front panel audio connector:Yes
- Front panel connector:Yes
- ATX Power connector (24-pin):Yes
- CPU fan connector:Yes
- Number of CPU fan connectors:2
- Number of chassis fan connectors:6
- EPS power connector (8-pin):Yes
- Number of EPS power connectors (8-pin):2
- TPM connector:Yes
- Number of water pump connectors:2
- RGB LED pin header:Yes
- Number of RGB LED pin headers:5
Rear panel I/O ports
- USB 2.0 ports quantity:2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:4
- USB4 Gen 2x2 ports quantity:2
- Ethernet LAN (RJ-45) ports:1
- HDMI ports quantity:1
- HDMI version:2.1
- DisplayPort version:1.4
- Headphone outputs:1
- Line-in:Yes
- S/PDIF out port:Yes
- WiFi-AP antenna jack:2
Network
- Ethernet LAN:Yes
- Ethernet interface type:5 Gigabit Ethernet
- LAN controller:Realtek RTL8126
- Wi-Fi:Yes
- Top Wi-Fi standard:Wi-Fi 7 (802.11be)
- Wi-Fi standards:Wi-Fi 7 (802.11be)
- WLAN controller model:Qualcomm QCNCM865
- Bluetooth:Yes
- Bluetooth version:5.3
Features
- Motherboard chipset:AMD X870
- Audio chip:Realtek ALC1220
- Audio output channels:7.1 channels
- Product colour:Black
- PC health monitoring:Fan, Temperature, Voltage
- Component for:PC
- Motherboard form factor:ATX
- Motherboard chipset family:AMD
- Windows operating systems supported:Windows 11 x64
Expansion slots
- PCI Express x4 slots:2
- PCI Express x16 (Gen 3.x) slots:1
- PCI Express x16 (Gen 4.x) slots:1
- PCI Express x16 (Gen 5.x) slots:1
- Number of M.2 (M) slots:4
- 1st M.2 largest key size:25110
- 1st M.2 highest PCI Express generation:5.0
- 2nd M.2 largest key size:22110
- 2nd M.2 highest PCI Express generation:5.0
- 3rd M.2 largest key size:22110
- 3rd M.2 highest PCI Express generation:5.0
- 4th M.2 largest key size:22110
- 4th M.2 highest PCI Express generation:4.0
BIOS
- BIOS type:UEFI AMI
- BIOS memory size:256 Mbit
- ACPI version:5.0
- Clear CMOS jumper:Yes
- Clear CMOS button:Yes
- Desktop Management Interface (DMI) version:2.7
- System Management BIOS (SMBIOS) version:2.7
Logistics data
- Country of origin:China
- Products per shipping (inner) case:1 pc(s)
Battery
- Battery weight:3 g
- Lithium weight per battery:0.07 g
- Number of battery cells:1
- Battery technology:Lithium-Manganese Dioxide (LiMnO2)
- Battery type:CR2032
Packaging data
- Package width:345 mm
- Package depth:294 mm
- Package height:80 mm
- Package weight:2.97 kg
Weight & dimensions
- Width:305 mm
- Depth:244 mm
- Height:35 mm
Packaging content
- Batteries included:Yes
- Antenna included:Yes
- Screws included:Yes
Other features
- Weight:2.54 kg
Technical details
- Warranty period:3 year(s)
