Gigabyte B850 Gaming X Wifi6e Motherboard - AMD Ryzen 9000 Series - 12+2+2 Phases - DDR5 - ATX

Gigabyte B850 Gaming X Wifi6e Motherboard brings next-gen features to AMD Ryzen 9000 Series builders, offering broad AM5 compatibility and a robust 12+2+2 phase power design for stable performance.

This ATX motherboard is built around the AMD B850 chipset and supports Socket AM5 processors from the AMD Ryzen 7000, 8000 and 9000 Series, making it a versatile foundation for gaming and productivity rigs running Windows 10 x64 or Windows 11 x64.

Memory support is modern and generous, with four DIMM slots for DDR5-SDRAM in dual-channel configuration and up to 256 GB total memory. The board accepts high-speed DDR5 kits up to 8200 MHz, and each slot can handle up to 64 GB for heavy multitasking and content creation workloads.

Storage and expansion are well catered for with three M.2 slots (one PCIe 5.0 x4 25110 and two PCIe 4.0 22110) plus four SATA III connectors, allowing up to seven drives in total and RAID 0/1/10 support for performance or redundancy. A single PCIe x16 Gen5 slot supports the latest GPUs.

Connectivity is extensive: HDMI 2.1 and DisplayPort 2.1 outputs, 2.5 Gigabit Ethernet (Realtek RTL8111H), Wi‑Fi 6E (802.11ax) with included antenna, Bluetooth 5.3, multiple USB ports including USB 3.2 Gen2 Type-A and Type-C, and HD audio powered by the Realtek ALC897 with 7.1-channel output.

Cooling and system monitoring are thorough, with support for two CPU fans, two water-pump connectors, comprehensive PC health monitoring (fan, temperature, voltage, water cooling), RGB LED headers (four) and convenient features like clear CMOS button and jumper. The board also includes TPM and front-panel connectors for easy case integration.

Use cases for the Gigabyte B850 Gaming X Wifi6e include a high-performance gaming PC with PCIe 5.0 GPU support, a compact workstation for video editing and 3D work relying on up to 256 GB DDR5 memory, or a connected home server using the M.2 and SATA capacity with RAID protection. Its Wi‑Fi 6E and 2.5GbE make it ideal for fast multiplayer gaming and streaming.

Key selling points: AM5 Socket for Ryzen 7000–9000 Series support, DDR5 up to 8200 MHz and 256 GB, PCIe 5.0 x16 slot, three M.2 slots with one PCIe 5.0, Wi‑Fi 6E + Bluetooth 5.3, 2.5GbE LAN, and robust 12+2+2 phase power delivery — all backed by a 3-year warranty.

• Socket AM5 for Ryzen 7000/8000/9000
• DDR5 up to 8200 MHz, 4 DIMM, 256 GB
• 3x M.2 (1x PCIe 5.0), 4x SATA III, RAID 0/1/10
• Wi‑Fi 6E, Bluetooth 5.3, 2.5 GbE
• PCIe 5.0 x16 slot and 12+2+2 phases
